APPLICATIONS:
Solar Suitable for cabling between interconnected solar modules or DC/AC inverter. (Photovoltaic power supply systems).
PRODUCT FEATURES:
- Tinned fine stranded copper conductor
- UV resistant
- Environmentally friendly
- Flame retardant
- Heat, oil and chemical resistant
CONSTRUCTION:
Conductor Annealed tinned copper stranded Class 5 for flexibility.
Insulation XLPO 120℃ Compound.
Sheath XLPO 120℃ Compound.
CHARACTERISTICS:
Operating Temperature Range -40℃ to 90℃.
Maximum Conductor Temperature 120℃.
Rated Voltage Uo/U 1.0/1.5kV DC Voltage.
Minimum Bending Radius Fixed 4 x cable diameter / Flexing 6 x cable diameter.
Sheath Colour Black, Black with Red stripe.
Standard Core Colours Black, Red.
Relative Standards AS/NZS 5033:2021, IEC 62930:2017, IEC 60332-1. ROHS Compliant and C E Certified.
