Single Phase DIN-rail watt-hour meter

A new kind of single phase electronic watt-hour meter that uses micro-electronic techniques to accurately and directly measure 50Hz or 60Hz active energy consumption from a single phase AC electricity network. Displays energy consumption by step type impulse register.



Click to download full series data sheet

Click to download Compliance Document

Quantity of item required. Cable is quoted in metres.

PRODUCT FEATURES:

  • 35mm standard DIN rail installation, complying with standard DIN EN5002
  • 18mm width, complying with standard DIN43880
  • 5 + 1 digits display (99999.1kWh)
  • Analogue display for visibility in sunlight
  • Impulse output
  • Wire Size: 6mm2

TECHNICAL PARAMETERS:

Accuracy Class 1
Rated Voltage 230V
Rated Current 32A
Starting Current 0.4% lb
Insulation Performance AC Voltage 2kV for 1 minute impulse voltage 6kV

COMPLIANCE DOCUMENT:

KWH Meters Certificate of Compliance

Product Code: DEMO15 Categories: , , ,
