MST000.50

1 x 0.5mm2


High Performance Flexible Appliance / Marine Wire 0.6/1kV 90°C


Keywords: MST, Single Core, Tinned Copper, Marine, Audio



Clear

Quantity of item required. Cable is quoted in metres.

APPLICATIONS:


Power Flexible thermal insulated wire suitable for switchboard wiring, motors and transformers.

Marine Tinned copper conductors for boat wiring and other marine applications.

Audio Amplifiers and audio equipment where oxygen-free copper wire is required.


PRODUCT FEATURES:



  • Tinned fine stranded copper conductor

  • UV stabilised

  • Flame retardant

  • Metre marked 0.5mm to 25mm for better length control.

  • Oil and chemical resistant (refer to Chemical Rating Chart)


CONSTRUCTION:


Conductor Annealed tinned copper stranded high flexibility (Class 5).

Insulation SPVC V-90HT.


CHARACTERISTICS:


Operating Temperature Range Fixed -20℃ to 90℃ / Flexing 5℃ to 75℃.

Maximum Conductor Temperature 105℃ (Current ratings are based on 30℃ air temp. See technical section for de-rating factors).

Rated Voltage Uo/U 0.6/1kV.

Minimum Bending Radius Fixed 10 x cable diameter / Flexing 15 x cable diameter.

Insulation Colour

0.5mm² .................Red, White, Blue, Black, Grey, Brown, Pink, Orange, Green/Yellow, Violet, Yellow.

0.75 - 4.0mm² .......Red, White, Blue, Black, Grey, Brown, Yellow, Violet, Orange, Green/Yellow, Pink.

6.0 - 10.0mm² .......Red, White, Blue, Black, Green/Yellow.

16.0 - 25.0mm² .....Red, White, Blue, Black, Green/Yellow.

Relevant Standards IEC 60228, IEC 60332-1, AS/NZS 3808, AS/NZS 3008.1, AS/NZS 3191, AS/NZS 1125, AS/NZS 5000.1, C E Directive 2006/95/EC, ROHS Compliant.


COMPLIANCE DOCUMENT:


Supplier Declaration of Conformity - SDoC AS/NZS 3191

No. of Cores x Size (mm²): 1 x 0.50

Approx Stranding (No. of wires x mm): 16/0.20

Approx. Overall Diameter (mm): 2.5

Approx. Weight (Kg/Km): 10

Nominal Amps enclosed protected from sun @ 30°C fixed installation (in duct or cabinet): 7

3 Phase Volt Drop @ 50Hz / MAX. Conductor Temp 90°C (Mv/Am): 86.100
