RH04/0.75G

4 x 0.75mm2


High Performance Flexible Energy Chain Control Cable 300/500V 80°C



Click to download full series data sheet

Click to download Compliance Document

Quantity of item required. Cable is quoted in metres.

APPLICATIONS:


Energy/Drag Chains Designed for continuous movement where tight bending radii is required.

Control and Signals As power control or signal cables on machines, portable tools, conveying equipment or similar industrial applications.


PRODUCT FEATURES:



  • Extra high flexibility suitable for continuous movement

  • Suitable for tight bending radii

  • UV stabilised

  • Flame retardant

  • Heat, oil and chemical resistant (see Chemical Rating Chart)


CONSTRUCTION:


Conductor Annealed plain copper stranded extreme flexibility (Class 5 & 6).

Insulation Special SPVC with the cores stranded together in layers (if needed) while each layer has a different lay direction:

1st layer – left direction.  2nd layer – right direction.

Each layer has a special wrapping for increased flexibility.

Sheath Special SPVC.


CHARACTERISTICS:


Operating Temperature Range Fixed -20°C to 80°C / Flexing -5°C to 80°C.

Maximum Conductor Temperature 80°C.

Rated Voltage Uo/U 300/500v Max AC Operating Voltage Uo 318v.

Minimum Bending Radius Fixed 5 x cable diameter / Flexing 7.5 x cable diameter.

Sheath Colour Grey.

Standard Core Colours Black (numbered) + 1 Green/Yellow Earth.

Max. speed 2m/s.

Max. acceleration 10m/s2.

Max. cycle >1 million.

Relevant Standards VDE 0295 Class 6, VDE 0281, VDE 0812, IEC 60332-1, IEC 60228, C E Directive 2006/95/EC, ROHS Compliant.


COMPLIANCE DOCUMENT:


RH Certificate of Compliance

Product Code: RH04/0.75G Categories: ,

No. of Cores x Size (mm²): 4 x 0.75

Approx. Stranding (No. of wires x mm): 42/0.15

Approx. Overall Diameter (mm): 6.4

Approx. Weight (Kg/Km): 77
