3 x 240.0mm2 + 3 x 35mm2

High Performance Flexible VSD Power Cable 0.6/1kV 90°C

Keywords: FDXCY, VSD Variable Speed Drive, Screened, Tinned Copper


Click to download full series data sheet

Click to download Compliance Document

Quantity of item required. Cable is quoted in metres.


VSD Connection Designed for the connection of AC Variable Speed Drives (VSD) or where a flexible EMC screened cable is required. These cables are flexible for fixed installation as well as occasional flexing without tensile load.

RFI & EMI Protection With double screening (CBS & foil tape) and split interstitial earth cores (6mm² and above), this cable has optimum screening performance of low frequency and electromagnetic output.


  • Helps avoid reactance with other devices outside the plant

  • UV stabilised

  • Flame retardant

  • Moisture resistant

  • Resistant to environmental factors such as oxidation, ozone and sunlight

  • To be earthed using an EMC compatible gland

  • Heat, oil and chemical resistant (see Chemical Rating Chart)


Conductor Annealed plain copper stranded high flexibility (Class 5).

Insulation X-90.

Screening 85% tinned copper braid screen c/w 100% foil screen coverage.

Sheath SPVC V-90.


Operating Temperature Range Fixed -20°C to 90°C / Flexing -5°C to 90°C.

Maximum Conductor Temperature 90°C (Current ratings are based on 30°C air temp. See technical section for de-rating factors).

Rated Voltage Uo/U 0.6/1kV.

Max AC Operating Voltage Uo 0.7kV.

Minimum Bending Radius 1.5mm² – 25mm²: Fixed 4 x cable diameter / Flexing 6 x cable diameter. 35mm² – 185mm²: Fixed 6 x cable diameter / Flexing 9 x cable diameter.

Sheath Colour Black.

Standard Core Colours Red, White, Blue, Green/Yellow.

Relevant Standards AS/NZS 5000.1, AS/NZS 1125, AS/NZS 3808, IEC 60332-1, ROHS Compliant.


Supplier Declaration of Conformity - SDoC AS/NZS 5000.1

Categories: ,

No. of Cores x Size:
Power + Earth  (mm²):
 3 x 240 + 3 x 35

Approx. Stranding Power (No. of wires x mm): 1225/0.50

Approx. Overall Diameter (mm): 59.9

Approx. Weight (Kg/Km): 8785

Nominal Amps un-enclosed protected from sun @ 30°C fixed application (Fixed Installation Touching): 519

3 Phase Volt Drop @ 50Hz / MAX. Conductor Temp 90°C (Mv/Am): 0.245
