CCEPR31

4 x 0.75mm²
Length Compressed:
0.5m
Length Extended: 2.0m


Extreme Performance Industrial Curly Cord Spiral Cables PUR Outer Sheath 1:4 Elasticity Ratio


Keywords: CC Series, Workshops, Laboratory, Power Tools, Food, Beverage





Click to download full series data sheet

Click to download Compliance Document

Quantity of item required. Cable is quoted in metres.

APPLICATIONS:


Mobile Tools Due to its long elastic memory and cable life, this cable is suitable for connection of mobile power tools in production lines, engineering and mechanical workshops and laboratory environments.

Food & Beverage With its microbe and hydrolysis resistant and super durable PUR sheath, this cable suits the food and beverage industry.


PRODUCT FEATURES:



  • Extreme abrasion resistance

  • Excellent elasticity and reverse bending strength

  • UV stabilised

  • Flame retardant

  • Resistance to microbes

  • Supplied with 200mm tails

  • Oil and chemical resistant (see Chemical Rating Chart)


CONSTRUCTION:


Conductor Annealed plain copper stranded high flexibility (Class 5).

Insulation EPR rubber.

Sheath Orange halogen free PUR polyurethane TMPU (HD22.1 S2).


CHARACTERISTICS:


Operating Temperature Range

Flexing -25°C to 90°C

Rated Voltage

0.75mm² to 1.0mm² - Uo/U 300/500V / 1.5mm² and above - Uo/U 0.6/1kV.

Standard Core Colours

3 core – Blue, Brown, Green/Yellow.

4 core – Blue, Brown, Black, Green/Yellow.

5 core – Blue, Brown, Black, Grey, Green/Yellow.

Relevant Standards IEC 60228, IEC 60332-1, C E Directive 2006/95/EC, ROHS Compliant.


COMPLIANCE DOCUMENT:


CC Series Certificate of Compliance

No. of Cores x Size (mm²): 4 x 0.75

Length Compressed: 0.5m

Length Extended: 2.0m
