APPLICATIONS:
Data Centers LSHF cables boost safety, minimize toxic emissions, ensure compliance, and provide reliable performance in high-density cabling applications.
Power Supply for Switchboards, flexible droppers from busbars, transformers, load banks or other equipment requiring fixed or flexible cable.
Welding Suitable for welding and electrode leads.
Generator Sets As leads for temporary power supplies.
Automotive Battery leads or jumpers, battery chargers, electric forklifts.
Telecommunications Where finely stranded large cross section cables are required for minimal volt drop.
Greenstar applications: PVC-free, Low Smoke Halogen Free construction suitable for sustainable building standards.
CONSTRUCTION:
Conductor: Annealed plain copper stranded extreme flexibility (Class 6)
Insulation: X-HF-110
CHARACTERISTICS:
Operating Temperature Range Fixed -25°C to 110°C
Maximum Conductor Temperature 110°C (Current ratings are based on 30°C air temp. See technical section for de-rating factors). Rated Voltage Uo/U 0.6/1kV.
Max AC Operating Voltage Uo 0.7kV.
Minimum Bending Radius Fixed 4 x cable diameter / Flexing 6 x cable diameter.
Colour Green/Yellow.
Relevant Standards IEC 60332-1, AS/NZS 5000.1, AS/NZS 1125, AS/NZS 3808, AS/NZS 3008, IEC 61034-2, IEC 60754-1, Compliant.
